Shuntour E03
3‑Lens 1080p Dash Camera with Night Vision & Parking Monitoring
3‑Lens Car DVR • 1920×1080 FHD • 170° Wide Angle • 24h Parking Monitor
|
3‑Lens Coverage
Front, interior and rear‑view recording for full vehicle coverage and evidence
|
170° Wide Angle
Ultra‑wide 170° lens angle to capture more lanes and blind spots
|
Night Vision
Enhanced low‑light performance for clear footage at night and in tunnels
|
24h Parking Monitor
Supports 24‑hour parking surveillance (with ACC hardwire kit)
|
Daily Driving
Rideshare & Taxi
Fleet & Delivery
Parking Security
The Shuntour E03 is a universal 3‑lens car DVR dash camera designed for comprehensive
front, cabin, and rear‑view recording. With Full HD 1920×1080 video resolution, a 170° large
viewing angle and support for night vision, it delivers clear evidence in both daytime and
low‑light conditions.
Supporting 12–24 V vehicle systems, automatic loop recording and 24‑hour parking monitoring
(with ACC hardwire kit), the E03 is ideal for personal vehicles, taxis, rideshare drivers and
fleets that require continuous video evidence and security.
Technical Specifications
Key Attributes
| Product name |
3 Lens Car DVR Camera (Shuntour E03) |
| Type |
Dash Cam, Video Recorder (Car DVR) |
| Brand / Model |
Brand: Shuntour • Model: E03 |
| Car fitment |
Universal (12–24 V vehicles) |
| Place of origin |
China |
Camera & Optics
| Number of lenses / cameras |
3 lenses / 3 cameras |
| Lens angle (overall) |
170° large wide‑angle view |
| Lens field of view (per lens) |
150°–180° (specified range) |
| Video resolution |
1920 × 1080 (1080 FHD) |
| Night vision |
Supported (Night Vision) |
Display & Installation
| Screen size / type |
3.0" IPS screen (TN screen type noted) |
| Installation position |
Windshield area (front glass mounting) |
Functions & Features
| Main functions |
Reversing camera support, loop recording, parking monitoring, rear‑view recording |
| Loop recording |
Auto loop recording (overwrites oldest footage when card is full) |
| Parking monitor |
Supports 24h parking monitoring (with ACC hardwire kit) |
| Special features |
Night vision, wide‑angle, rear‑view recording, parking monitoring |
| Wi‑Fi |
Supports 2.4G / 5G Wi‑Fi (for configuration / video access – depending on model firmware) |
| Warranty |
1 Year |
Electrical & Environmental
| Input voltage (power) |
12–24 V (vehicle power supply) |
| Internal battery |
150 mAh (backup battery) |
| Working temperature range |
‑20 °C to +60 °C |
Storage, Memory & Packaging
| Memory card support |
microSD, up to 128 GB max (not included) |
| Selling units |
Single item |
| Single package size |
15 × 11 × 7 cm |
| Single gross weight |
0.450 kg |
All specifications are provided by the manufacturer and are subject to change without prior notice.
Functionality such as Wi‑Fi, parking monitoring and multi‑camera recording may depend on installation
quality, memory card performance and power connection (e.g. hardwire kit for 24h monitoring).
